Digital Temperature Controls

• Advanced PID controller, Covers most applications
• LED Dual display , 4 digits
• Fuatures :
> Universal input, Auto tune, Selectable lower display,
> Single point ramp-soak, Heat-Cool PID, Soft start,
Auto/Manual mode
• Input sensor type :
> Thermocouple ( J,K,T,R,S,C,E,B,N,L,U,W )
> RTD ( PT100 )
> Singnal Input (DC) : -5 to 56mV, 0 – 10V, 0 – 20mA
• Output Control :
> Relay or SSR
> Current : 0/4 to 20mA ( max load 500E )
> Voltage : 0 – 50/10VDC ( max load 10K )
• Auxiliary output : 2 (Relay or SSR drive voltage)
• Mode : Set poit or Alarm mode
• Alarm modes : Deviation, Absolute, Hight, Low, Band
,Sensor break
• Control action : PID or ON-OFF
• Input voltage : 85 – 270 V AC/DC, 50/60Hz
